Gas-Heating Flexible Chest Ironer
Applicable Industry:
Details Display
Flexible Chest
The Kingstar Automation gas heating flexible chest ironer is designed by a team of experienced European engineers. It is equipped with an independent thermal oil heating boiler. The thermal oil directly heats the iron. It is designed using the principle of fluid mechanics and tested repeatedly. The surface heating coverage reaches more than 97%, and the surface temperature of the ironing tank is controlled at about 200 degrees. The ironing quality is good, and the cost of use is low. It is a truly efficient and energy-saving ironer.
Direct Motor Drive
The independent motor is used to directly drive each drum, so it solved the problem of the limitations of synchronous belts or rolls on each drum speed difference. The speed difference between each drum can even be set according to the type of linen.
Stability
The flexible chest ironer is provided by a professional manufacturer of chest ironers in Belgium. It is tested by high-pressure inflation and has stable and reliable quality.
Energy Efficiency
Kingstar Automation gas heating flexible chest ironer takes no more than 15 minutes to heat up from 0°C to 200°C. The ironing speed of the quilt cover can reach 35 meters/minute.
Technical Parameter
|
Model |
1chest |
2chest |
3chest |
|
|
Boiler Thermal Power |
200kw |
350KW |
500KW |
|
|
Boiler Electric Power |
8.25kw |
8.25kw |
11.75kw |
|
|
Gas Pipe Connector |
DN25 |
DN40 |
DN40 |
|
|
Dehumidification Capacity |
1.1KW |
2.2KW |
2.2KW |
|
|
Maximum Power Consumption |
21.45KW/h |
33.55KW/hour |
48.05KW/hour |
|
|
Capacity |
300-350 pieces/hour |
600-700 pieces/hour |
1000-1200 pieces/hour |
|
|
Maximum Natural Gas Consumption |
20m³/hour |
28m³/hour |
40m³/hour |
|
|
Ironing Speed |
5-15 meter/min |
5-30 meter/min |
5-50 meter/min |
|
|
Dimension(L×W×H )mm |
3300mm |
3490×4740×3080 |
5070×4740×3080 |
6630×4740×3080 |
|
3500mm |
3490×4940×3080 |
5070×4940×3080 |
6650×4940×3080 |
|
|
4000mm |
3490×5440×3080 |
5070×5440×3080 |
6650×5440×3080 |
|
|
Weight（KG） |
3300mm |
4550 |
12310 |
16350 |
|
3500mm |
4750 |
12510 |
16550 |
|
|
4000mm |
5250 |
13010 |
17050 |
|
