Tunnel Finisher
Applicable Industry:
Details Display
Full Insulation Process
High-density thermal insulation cotton is used to cover the entire drying area, so that heat can always be maintained inside the machine, saving energy.
Steam Injection Technology
Can preheat clothes to ensure drying effect and ironing quality
Mitsubishi PLC Control System
Precisely control the operation cycle process of steam, heating unit and hot air
Modular Design
It adopts a unique, compact modular design and occupies a small area. The feeding discharging and operating areas of the machine are all designed on the same side. and the machine can be installed against the wall.
Technical Parameter
TF3-S Steam Heated Tunnel Finisher Series
| Parameter | TF3-2S | TF3-3S | TF3-4S | TF3-5S | TF3-6S |
| Heating Method | Steam | Steam | Steam | Steam | Steam |
| Drying Modules | 1 | 2 | 3 | 4 | 5 |
| Cooling Modules | 1 | 1 | 1 | 1 | 1 |
| Capacity (pcs/hour) | 300-400 | 700-800 | 1000-1200 | 1400-1600 | 1800-2000 |
| Steam Consumption (kg/h) | 120 | 240 | 360 | 480 | 600 |
| Steam Pressure (bar) | 5-7 | 5-7 | 5-7 | 5-7 | 5-7 |
| Steam Inlet | DN40 | DN40 | DN50 | DN50 | 2-DN40 |
| Condensate Outlet | DN40 | DN40 | DN40 | DN40 | DN40 |
| Compressed Air Inlet (mm) | 8 | 8 | 8 | 8 | 8 |
| Conveyor Motor (kW) | 0.25 | 0.25 | 0.37 | 0.55 | 0.55 |
| Exhaust Fan (kW) | 2.2×2 | 2.2×2 | 2.2×2 | 2.2×2 | 3×2 |
| Circulation Fan (kW) | 4×4 | 4×6 | 4×8 | 4×10 | 4×12 |
| Lint Removal Motor (kW) | 0.06 | 0.06 | 0.06 | 0.06 | 0.06 |
| Total Power (kW) | 20.71 | 28.71 | 36.83 | 45.01 | 54.61 |
| Dimensions (L×W×H mm) | 6285×2090×3002 | 7785×2090×3002 |
9285×2090×3002 | 10785×2090×3002 | 12285×2090×3002 |
| Weight (kg) | 3200 | 5600 | 7000 | 8400 | 9800 |
TF3-G Gas Heated Tunnel Finisher Series
| Parameter | TF3-2G | TF3-3G | TF3-4G | TF3-5G | TF3-6G |
| Heating Method | Gas | Gas | Gas | Gas | Gas |
| Drying Modules | 1 | 2 | 3 | 4 | 5 |
| Cooling Modules | 1 | 1 | 1 | 1 | 1 |
| Capacity (pcs/hour) | 300-400 | 700-800 | 1000-1200 | 1400-1600 | 1800-2000 |
| Gas Inlet | DN25 | DN40 | DN40 | DN50 | DN50 |
| Gas Pressure (kPa) | 8-12 | 8-12 | 8-12 | 8-12 | 8-12 |
| Gas Consumption (m3/h) | 10-12 | 15-18 | 20-24 | 26-30 | 32-36 |
| Steam Consumption (kg/h) | 40 | 50 | 60 | 70 | 80 |
| Steam Pressure (bar) | 5-7 | 5-7 | 5-7 | 5-7 | 5-7 |
| Steam Inlet | DN20 | DN20 | DN20 | DN20 | DN25 |
| Condensate Outlet | DN15 | DN15 | DN15 | DN15 | DN20 |
| Spray Cold Water Inlet | DN25 | DN25 | DN25 | DN25 | DN25 |
| Compressed Air Inlet (mm) | 8 | 8 | 8 | 8 | 8 |
| Conveyor Motor (kW) | 0.25 | 0.25 | 0.37 | 0.55 | 0.55 |
| Exhaust Fan (kW) | 2.2×2 | 2.2×2 | 2.2×2 | 2.2×2 | 2.2×2 |
| Circulation Fan (kW) | 4×4 | 4×6 | 4×8 | 4×10 | 4×12 |
| Lint Removal Motor (kW) | 0.06 | 0.06 | 0.06 | 0.06 | 0.06 |
| Burner Fan (kW) | 0.75 | 0.75×2 | 0.75×3 | 0.75×4 | 0.75×5 |
| Total Power (kW) | 21.46 | 30.21 | 39.08 | 48.01 | 56.76 |
| Dimensions (L×W×H mm) | 6285×2090×3002 | 7785×2090×3002 |
9285×2090×3002 | 10785×2090×3002 | 12285×2090×3002 |
| Weight (kg) | 3150 | 5550 | 6590 | 8350 | 9750 |
Configuration Standards
| Control system | Mitsubishi | Japan |
| Gear motor | Bonfiglioli | Italy |
| Electric components | Schneider | France |
| Proximity switch | Omron | Japan |
| Inverter | Mitsubishi | Japan |
| Cylinder | CKD | Japan |
| Trap | VENN | Japan |
| Fan | Indeli | China |
| Radiator | Sanhe Tongfei | China |
