800 Series Super Roller Ironer
Applicable Industry:
Details Display
6 Reasons For High Speed
- Heat: Boiler steel cylinders (2.5× stainless conductivity).
- Moisture: 4 inlet rollers evaporate 30% linen moisture.
- Ironing: 270° wrap + double-sided, better cover quality.
- Build: 12mm cabinet, 14.5t, CNC-cut for strength.
- Cylinders: 11-12mm thick (1MPa resistance), even heating.
- Precision: Heavy frame, machined parts, 60m/min max.
Auto Temp Regulation (Bed Sheets)
Auto-adjusts steam pressure (1.5~2.5) to avoid over-ironing/waste; ≥60m/min speed.
Energy-Saving
- 4.75kw inverter motor.
- Insulated parts: 5% less steam.
- Mitsubishi PLC: ~25% lower steam vs ordinary.
Safety Design
- Cylinders: 11-12mm boiler steel (1.5MPa rated, 1MPa max).
- Remote control: safe belt/roller replacement.
- Valve: shuts off steam over 1MPa.
High Quality Flatness Design
- Rust-proof cylinders: no residue, flat ironing.
- 3-cylinder double-sided heating: better flatness/efficiency.
- Auto-tension belts: no wrinkles.
Stability Design
Heavy-Duty Structure: 14.5-ton heavy mechanical design for stability.
Imported Components: Electrical, pneumatic, transmission parts, belts, traps are high-quality imports.
Precision Guide Rolls: High-precision steel guide rolls ensure belt alignment and ironing quality.
Technical Parameter
|
Specification Model |
GYP-3300Z-800IV (Four Rolls) |
GYP-3300Z-800VI (Six Rolls) |
GYP-3500Z-800VI (Six Rolls) |
GYP-4000Z-800VI (Six Rolls) |
|
Drying Cylinder Length (mm) |
3300 |
3300 |
3500 |
4000 |
|
Drying Cylinder Diameter (mm) |
800 |
800 |
800 |
800 |
|
Ironing Speed (m/min) |
≤60 |
≤60 |
≤60 |
≤60 |
|
Steam Pressure (MPa) |
0.1~1.0 |
0.1~1.0 |
0.1~1.0 |
0.1~1.0 |
|
Motor Power (kw) |
6.25 |
6.25 |
6.25 |
6.25 |
|
Total Weight (kg) |
10100 |
14500 |
15000 |
15500 |
|
Overall Dimensions (mm) (Length×Width×Height) |
4090×4750×2155 |
5755×4750×2155 |
5755×4980×2155 |
5755×5470×2155 |
