Centrifugal Extractor

Short Description:

Effectively protects buttons, zippers and other garment accessories during extraction;

65kg capacity, max extraction speed 830 rpm, centrifugal force up to 500G;

180s operating cycle driven by an imported servo high-torque motor;

1–5 extraction levels for precise, gentle or powerful dewatering;

Fully suspended cylinder design for low vibration and low noise;

Self-developed PLC system with multiple intelligent safety protections;

Water recycling system reuses extracted water to save resources.

Applicable Industry:

Send email to us Product Video

Product Detail

Details Display

Smart Control

Equipped with a large dot-matrix LCD screen and an intelligent central control system, the machine features a user-friendly interface for easy operation.

Stable & Reliable

The self-developed PLC control system with multiple built-in intelligent safety protection functions ensures stable, safe, and long-lasting operation.

Servo Control

Variable frequency drive ensures energy-efficient operation, low noise, and reduced power consumption.

Smart Speed Adjustment

Provides 1–5 extraction levels for different textile types, enabling precise, gentle, or powerful extraction performance.

High-Speed & Efficient

With an operating cycle of 180 seconds, the imported servo high-torque motor enables a maximum extraction speed of 830 rpm. The centrifugal force can reach 500 G while ensuring safe operation. The inner drum features large perforations for rapid water drainage.

Low Noise & Vibration Reduction

The machine uses a fully suspended cylinder design, significantly reducing vibration and noise during operation to ensure stable, safe, and reliable performance.

Water Recycling & Energy Saving

Equipped with a water recycling system, the extractor collects and reuses extracted water to reduce resource consumption.

Technical Parameter

Model	LXJ-65
Load Capacity (kg)	65
Centrifugal Force (G)	500
Maximum Speed (rpm)	830
Total Montor Power (kW)	30.97
Power Supply (V/Hz)	380
Air Pressure (MPa)	0.4-0.8
Dimensions (mm) L × W × H	3565×2360×2510
Total Weight (kg)	4450
