Towel Folder With Mechanical Folding Blades

Short Description:

Fast speed: The Towel Folder With Mechanical Folding Blades has a grating automatic recognition system, which can run as fast as the human hand speed.

Neat and efficient: full knife folding is more neat, automatic identification and sorting of all kinds of linen (bath towel, floor towel, towel, etc.), and automatic adjustment of procedures.


Applicable Industry:

Laundry Shop
Laundry Shop
Dry Cleaning Shop
Dry Cleaning Shop
Vended Laundry(Laundromat)
Vended Laundry(Laundromat)
  • facebook
  • Linkedin
  • youtube
  • ins
  • asdzxcz1
X

Product Detail

Details Display

Technical Features

1. The knife-fold towel folder is adjustable in height to meet the needs of operators of different heights. The feeding platform is lengthened to make the longer towel have better adsorption.

2. Compared with similar equipment, T. towel has the fewest moving parts and all standard parts. In addition, the Towel Folder With Mechanical Folding Blades has better adjustability when replacing the drive belt.

3. The full knife folded towel will fall directly onto the special pallets below. When the pallets reach a certain height, they will be pushed to the final conveyor belt (included in the equipment). The conveyor belt can be placed on the left or right side of the towel folding machine, so as to convey the cloth to the front or rear end of the equipment.

4. T. towel full knife folding towel folding machine can classify and fold all kinds of towels. For example, the maximum folding length of bed sheets, clothing (T-shirts, nightgowns, uniforms, hospital clothing, etc.), laundry bags, and other dried linen can reach 2400mm.

5. Towel Folder With Mechanical Folding Blades can automatically identify and classify according to the length of various types of linen, so there is no need to sort in advance. If the same length of linen requires different folding methods, the Towel Folder With Mechanical Folding Blades can also choose to classify according to the width.

Technical Parameter

Maximum Folding Size 2100×1200mm
Compressed Air Pressure 5-7bar
Compressed Air Consumption 50L/min
Air Supply Pipe Diameter Ф16mm
Power Supply Requirements 3 phase 380V 50/60HZ
Power Cable Diameter 5×4mm²
Power 1.94kw
Dimensions(Length × Width × Height) Front Discharge 5330×2110×1420mm
Rear Discharge 5750×2110×1420mm
Two-in-One Rear Discharge 5750×3630×1420mm
Weight 1200 kg
