S-Single-Lane Single-Stack Folder
Applicable Industry:
Details Display
High Speed
The maximum speed can reach 60 meters/minute with smooth running.
Low error rate: The probability of jammed linen is extremely low. Even if it is blocked, the blocked sheets can be taken out within 2 minutes.
Good stability: The whole machine is rigid. The accuracy of the transmission component is very high. All parts are made of high-quality imported parts.
Software Communication
The CLM Single-Lane Single-Stack Folder can communicate with the spreading feeder and ironer to realize software and program communication.
PLC System
The precise folding requires precise control. The CLM folder uses the Mitsubishi PLC control system, a 7-inch touch screen, and stores more than 20 folding programs and 100 customer information. Equipped with Internet functions such as remote fault diagnosis, failure exclusion, and program upgrade.
Sheets Corners Flattening Device
As an option, we set up a device for flattening the corners of sheets at the end of the entrance of the feeding platform to perfectly eliminate the wrinkles.
Stacker
The stacking system of the CLM high-speed folder is a standard configuration. With the stacker, the operator does not need to frequently bend down to get the sheets and it prevent fatigue and improve working efficiency. The stacker conveyor adopts the powerless roller design. Even the operators left short time,the sheets will not jamed.
Moisture Suction System
Powerful moisture suction system is installed for each drum.
Technical Parameter
| Model | ZD-3300-V60 | Notes | |
| Max folding width(mm) | Single-lane Option | 1100-3300 | For Sheets and duvet covers |
| Four-lanes Option | 350-700 | 2 folds for pillowcases | |
| Stacking quantity (pcs) | 1-10 | For sheets and duvet covers | |
| Pillowcase capacity (pcs) | 1-4 | For pillowcases | |
| Max conveyor speed (m/min) | 60 | ||
| Air pressure (MPa) | 0.5-0.7 | ||
| Compressed air consumption(L/min) | 450 | ||
| Voltage (V/Hz) | 380/50 | 3phase | |
| Power(kW) | 3.6 | Stacker included | |
| Dimension(mm) W×D×H | 4870×5480×1920 | Stacker included | |
| Weight (kg) | 3200 | Stacker included | |
